Bondsure® TPO Waterproofing Membrane Weather Resistant Self Adhesive Butyl Waterproofing Membrane

Bondsure® TPO Waterproofing Membrane Weather Resistant Self Adhesive Butyl Waterproofing Membrane

Place of Origin: CHINA
Brand Name: JOABOA TECH
Certification: FM APPROVALS, CE, BBA, SGS, ISO, SIRIM
Model Number: TPO
Minimum Order Quantity: 1,000㎡
Packaging Details: With or without pallets; For 1.5mm thickness, 12,000㎡ can be loaded into 1x20GP if without pallets.
Supply Ability: 10,000,000㎡ per Month
Type: Self Adhered TPO,Peel And Stick TPO
Product Details
Place of Origin
CHINA
Brand Name
JOABOA TECH
Certification
FM APPROVALS, CE, BBA, SGS, ISO, SIRIM
Model Number
TPO
Type:
Self Adhered TPO,Peel And Stick TPO
Minimum Order Quantity
1,000㎡
Packaging Details
With or without pallets; For 1.5mm thickness, 12,000㎡ can be loaded into 1x20GP if without pallets.
Supply Ability
10,000,000㎡ per Month
High Light:

Bondsure TPO Waterproofing Membrane

,

JOABOA TPO Waterproofing Membrane

,

Butyl Waterproofing Membrane

Product Description

Bondsure™ Membrane Series



Bondsure® TPO Weather Resistant Butyl Self Adhesive Waterproofing Membrane is TPO waterproofing systems pecially developed for leakage maintenance engineering. It is composed of homogeneous TPO polymer sheet, polymer butyl rubber layer and isolation film. It has the characteristics of convenient construction, good bonding effect, high tensile strength, high elongation, chemical corrosion resistance and aging resistance. It can be applied to waterproof maintenance projects of various buildings.

Bondsure® TPO Waterproofing Membrane Weather Resistant Self Adhesive Butyl Waterproofing Membrane 0
Bondsure® TPO Waterproofing Membrane Weather Resistant Self Adhesive Butyl Waterproofing Membrane 1


※  Material Features

1. Excellent Aging Resistance



The warranty period of different materials is 5 years and 20 years, and the actual service life is longer.



2.  Strong Chemical Corrosion Resistance



It has the ability to resist acid, alkali and salt corrosion, and can be directly exposed for use.



3.  Excellent Physical and Mechanical Properties



High tensile strength, large elongation and strong resistance to structural deformation.



4.  Soft Material and Good Adhesion



It can provide various thickness specifications such as 0.9mm and 1.2mm.



5. Simple Construction, Safe and Environmentally Friendly



Self-adhesive, wet-applied and other construction methods can be selected depending on the different situation.

The construction is simple and there is no solvent or fire in the process, which is safe and environmentally friendly.



6. Reduce Energy Consumption and Energy Saving

The light colored surface can reflect sunlight.



7. Excellent Low Temperature Flexibility



Joaboa Tech's TPO Waterproofing has passed -50℃ low temperature flexibility test, that's why it can become a top brand of TPO waterproofing membrane in Mongolia, to compete with international brands.



 Bondsure® TPO Waterproofing Membrane Weather Resistant Self Adhesive Butyl Waterproofing Membrane 2





※  Scope of Application



Bondsure® Self Adhesive TPO Rofing is suitable for waterproof maintenance of various exposed and non-exposed concrete roofs, light steel roofs, glass daylighting roofs and so on

Bondsure® TPO Waterproofing Membrane Weather Resistant Self Adhesive Butyl Waterproofing Membrane 3

Bondsure® TPO Waterproofing Membrane Weather Resistant Self Adhesive Butyl Waterproofing Membrane 4



※ Construction Methods

Self Adhered TPO Membrane can use construction method as below: Wet Application, Peel and Stick, etc.



Maintenance and Repair on Concrete Roof with Self-adhesive TPO



Bondsure® TPO Waterproofing Membrane Weather Resistant Self Adhesive Butyl Waterproofing Membrane 5

Bondsure® TPO Waterproofing Membrane Weather Resistant Self Adhesive Butyl Waterproofing Membrane 6

Bondsure® TPO Waterproofing Membrane Weather Resistant Self Adhesive Butyl Waterproofing Membrane 7







Maintenance and Repair on Color Steel Sheet Roof with Self Ahesive TPO Membrane



Bondsure® TPO Waterproofing Membrane Weather Resistant Self Adhesive Butyl Waterproofing Membrane 8



Bondsure® TPO Waterproofing Membrane Weather Resistant Self Adhesive Butyl Waterproofing Membrane 9



Maintenance and Repair on Glass Daylighting Roof with Self-ahesive TPO



Bondsure® TPO Waterproofing Membrane Weather Resistant Self Adhesive Butyl Waterproofing Membrane 10



Bondsure® TPO Waterproofing Membrane Weather Resistant Self Adhesive Butyl Waterproofing Membrane 11





Construction Points



1. During construction, the surface of the base layer should be cleaned to maintain suffiffifficient strength and cleanliness, and there should be no quality problems such as dusting, powdering, hollowing, and rust. If necessary, special treatment agent should be applied.

2. It is forbidden to wear spiked shoes and step on the waterproof layer.

3. When using this material for local maintenance, the overlapping parts with the old waterproof layer should be cleaned up, the detailed parts should be handled in place and sealed tightly.

4. During the construction of wet-applied method, the materials need to be customized and matched with special bonding mortar.

5. It is strictly prohibited to place sharp objects directly on the completed waterproof layer without protective measures.
It is not allowed to consign heavy utensils and transportation equipment on the unprotected waterproof layer.
It is strictly prohibited to make holes on the completed waterproof layer.
In case of damage, it is necessary to timely notify the waterproof unit for repair.



※  Storage and Transport



1. Products of difffferent types and specififications shall be stacked separately and shall not be mixed.

2. It should be protected from sunlight, rain and under ventilated.

3. The storage temperature should be under 45℃and the membrane shall not be placed horizontally,

but stacked in a single layer when placed vertically.

4. Prevent tilting or side pressure during transportation, and cover it if necessary.

5. Under normal storage and transportation conditions, the storage period is one year from the production date.



※  Brand  Stature



Joaboa Tech is the 1st editor of China National Standard for TPO Waterproofing, GB27789-2011, who has enjoyed great reputation in Chinese domestic market for over 20 years, Joaboa Tech's TPO Membrane has been widely used in Mongolia, India, Chile, Peru, Thailand, etc.



Bondsure® TPO Waterproofing Membrane Weather Resistant Self Adhesive Butyl Waterproofing Membrane 12

Bondsure® TPO Waterproofing Membrane Weather Resistant Self Adhesive Butyl Waterproofing Membrane 13





※  International Cerfificate



Joaboa Tech Bondsure® TPO Waterproofing Membrane has already passed the strictest and highest roofing test- FM Approvals long time ago.



Being as the Pioneer of High Quality Waterproof System in China, Joaboa Tech is producing the best quality TPO Waterproofing Membrane that can compete with international brands in the global market.



That's why Joaboa Tech's TPO Watetproofing can be used in 140,000 Mega TCL Industrial Park Zone Project in India, and widely used in Mongolia where the temperature can be as low as close to -50℃.



Bondsure® TPO Waterproofing Membrane Weather Resistant Self Adhesive Butyl Waterproofing Membrane 14



Bondsure® TPO Waterproofing Membrane Weather Resistant Self Adhesive Butyl Waterproofing Membrane 15

Bondsure® TPO Waterproofing Membrane Weather Resistant Self Adhesive Butyl Waterproofing Membrane 16

Bondsure® TPO Waterproofing Membrane Weather Resistant Self Adhesive Butyl Waterproofing Membrane 17



※  Document Download



Joaboa Tech Bondsure® TPO Weather Resistant Butyl Self Adhesive Waterproofing Membrane
